Image Sensor： 1/2.7" Progressive Scan CMOS
Max. Resolution： 3840 × 2160
Shutter Time： 1/3 s to 1/100,000 s
Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
Day ＆ Night： IR cut filter
Lens Type： Fixed focal lens, 2.8 and 4 mm optional
Focal Length ＆ FOV： 2.8 mm, horizontal FOV 113°, vertical FOV 62°, diagonal FOV 134°
Supplement Light Type： IR, White Light
Supplement Light Range： Up to 30 m
Smart Supplement Light： Yes
Main Stream： 50 Hz: 12.5 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream： 50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression： Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
Region of Interest (ROI)： 1 fixed region for main stream
Environment Noise Filtering： Yes
Audio Sampling Rate： 8 kHz/16 kHz
Audio Compression： G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Security： Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Simultaneous Live View： Up to 6 channels
API Open Network Video： Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK, Hik-Connect
Protocols： TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP,UPnP
User/Host： Up to 32 users 3 user levels: administrator, operator, and user
Client： iVMS-4200, Hik-Connect
Web Browser： Plug-in required live view: IE 10, IE 11,
